The pragmatic way for contacting prismatic cells: the KEP-500.

The KEP-500 contacting system is a purposely simple solution for contacting prismatic battery cells. It makes ideal use of the mechanical space available and takes advantage of the set-up in the test chamber: instead of contacting the cell using fault-prone bolts, the system is placed on the adjacent clamping plates. Spring-loaded contacts ensure constant contacting conditions and therefore prevent the dangerous build-up of heat.

We have been incorporating our own experiences with testing into the development of the system on an ongoing basis and have ensured that the design and usability meet the demands of everyday testing in full. High-quality materials and a simple but well-designed build ensure that you can use the system intensively for a long time. The KEP-500 represents a simple and inexpensive way of contacting braced prismatic cells.

slide 3 of 2
The underside of the KEP-500 with spring-loaded, gold-plated contact element.
1 / 2

  • Pragmatic solution

    Designed for easy integration

  • Intelligent design

    Smart use of the installation space available

  • Fast contacting

    In consistently accurate quality

  • High-quality materials

    For use under demanding conditions

Features at a glance

KEP-500

The KEP-500 represents a pragmatic solution for contacting braced prismatic cells.

slide 1 of 1

Technical Specifications

KEP-500

Ampacity

300 A; higher currents available on request

Temperature range

-40 °C … +80 °C
